TN 涡轮纳米砂磨机
纳米研磨
TN 涡轮纳米砂磨机
工艺特性
◆  理想的单/多通道式或循环式生产工艺,连续不断的高效能实现了粒径的最窄化分布;
◆  涡轮加速器使研磨珠产生有力的流体运动,从而保证了持续恒定的能量输入;
◆  能量利用率高,整机能耗低;

工艺特性

◆  理想的单/多通道式或循环式生产工艺,连续不断的高效能实现了粒径的最窄化分布;
◆  涡轮加速器使研磨珠产生有力的流体运动,从而保证了持续恒定的能量输入;
◆  能量利用率高,整机能耗低;
◆  可以处理从低到高粘度的物料;
◆  理想的冷却特性允许处理对温度敏感物料;
◆  研磨珠的独特流体运动保障了流畅的研磨过程。


Properties of the Process
◆  Designed for running in single/multi-pass or circulation, with a constant efficiency in both processes for the achievement of narrow particle size distributions.
◆  Turbine accelerator a powerful, hydraulic movement of the beads which guarantee a high and constant energy input.
◆  The mill has a low energy uptake due to its efficient energy input.
◆  Ability to handle low to highly viscous products.
◆  Ideal cooling properties allow the processing of temperature sensitive products.
◆  Gentle processing as a result of hydraulic movement of the beads.


优势表现

◆  更高的流量;
◆  更好的高粘度物料处理能力;
◆  更长的分离筛网寿命;
◆  提高了对发泡物料处理能力;
◆  在纳米范围内的研磨能力;
◆  在生产中维护保养简单快捷;
◆  低成本的物料切换;
◆  通道模式和循环模式的优化组合。


Superiority performance
◆  Much higher throughputs.
◆  Better ability to process highly viscous products.
◆  Longer lifetime of the screen.
◆  Improved ability to handle foaming products.
◆  Ability to grind in the nanometre range.
  Simple handling of the machine during the production and the maintenance.
◆  Possibility for fast product changes at low costs.
◆  Optimal suitability for the pass mode and the circulation mode.

应用领域 Application domain

  ●  油漆和清漆
  ●  印刷油墨
  ●  涂料
  ●  颜料和染料
  ●  喷墨
  ●  汽车漆
  ●  陶瓷
  ●  半导体

  ●  医药学
  ●  食品行业
  ●  农用化学品
  ●  化妆品行业
  ●  造纸行业
  ●  生命科学
  ●  微生物学
  ●  填料

  ●  Paints and varnishes
  ●  Printing inks
  ●  Coatings
  ●  Pigments and dyes
  ●  Jet
  ●  Automobile coatings
  ●  Ceramic
  ●  Semiconductor

  ●  Pharmaceutical
  ●  Food industry
  ●  Agrochemicals
  ●  Cosmetics
  ●  Paper industry
  ●  Life sciences
  ●  Microbiology
  ●  Filling



技术参数 Technical parameters

型号 TypeTN-2TN-10TN-18TN-30TN-60

  研磨腔容积
  Vessel capacity (L)

210183060

  主机功率
  Main unit power (kw)

5.5~7.515~2230~3737~4555~90

  冷却水消耗
  Cooling water (L/h)

1000~15001500~22001800~25002500~30003000~4000
